Paso 4: codificación!
Puede utilizar el código que se muestra a continuación en el ide de Arduino.
Para obtener el 1sheeld bibliotecas de trabajo deben seguir el 1sheeld oficial consigue empezar tutorial aquí
El código se ha subido a mi página de Github:
// Project By Geeve George#define CUSTOM_SETTINGS #define INCLUDE_TEXT_TO_SPEECH_SHIELD #define INCLUDE_VOICE_RECOGNIZER_SHIELD #define CUSTOM_SETTINGS #define INCLUDE_MIC_SHIELD #define INCLUDE_SMS_SHIELD/* Include 1Sheeld library. */ #include int ledPin = 13; float sinVal; int toneVal;/* A command which will be compared. */const char firstCommand[]="what is the temperature now";/* A command which will be compared. */ const char secondCommand[]="how is the weather today";/* A command which will be compared. */ const char thirdCommand[]="did i leave the lights on";const char fourthCommand[]="lights on";const char fifthCommand[]="lights off";const int pinTemp = A0; // pin of temperature sensorfloat temperature; int B=3975; float resistance;/* A name for the LED on pin 13. */int pinLight = A1;void setup() { /* Start communication. */ OneSheeld.begin(); /* Set the LED pin as output. */ pinMode(ledPin,OUTPUT); pinMode(8, OUTPUT); }void loop() { /* Always check if a new voice command received. */ if(VoiceRecognition.isNewCommandReceived()) { /* Check if the voice command is the desired one. */ if(!strcmp(firstCommand,VoiceRecognition.getLastCommand())) { int val = analogRead(pinTemp); // get analog value resistance=(float)(1023-val)*10000/val; // get resistance temperature=1/(log(resistance/10000)/B+1/298.15)-273.15; int n= temperature ; String stringMsg="The Temperature is :"; stringMsg += String(n); stringMsg +="degree celcius sir"; //Convert our message to a character array so as to tweet it to twitter char msg[140]; stringMsg.toCharArray(msg, 140); TextToSpeech.say(msg); } /* Check if the voice command is the desired one. */ else if(!strcmp(secondCommand,VoiceRecognition.getLastCommand())) { int val = analogRead(pinTemp); // get analog value resistance=(float)(1023-val)*10000/val; // get resistance temperature=1/(log(resistance/10000)/B+1/298.15)-273.15; int n= temperature ; String stringMsg="The Temperature is :"; stringMsg += String(n); stringMsg +="degree celcius sir"; //Convert our message to a character array so as to tweet it to twitter char msg[140]; stringMsg.toCharArray(msg, 140); if(n >= 40) { /* 1Sheeld responds using text-to-speech. */ TextToSpeech.say("the weather is pretty harsh sir"); } else if(n >= 30 && n <= 39) { TextToSpeech.say("it is pretty hot outside sir"); } else if(n >= 27 && n <= 29) { TextToSpeech.say("The weather is pretty warm sir"); } else if(n >= 23 && n <= 26) { TextToSpeech.say("The weather is good sir"); } else if(n >= 18 && n <= 22) { TextToSpeech.say("The weather is moderate sir"); } else if(n >= 14 && n <= 17) { TextToSpeech.say("It is a mild weather sir"); } else if(n >= 10 && n <= 13) { TextToSpeech.say("It is a pretty cool weather sir"); } else if(n >= 6 && n <= 9) { TextToSpeech.say("It is a cold weather sir"); } else if(n >= 0 && n <= 5) { TextToSpeech.say("It is a very cold weather sir"); } } /* Check if the voice command is the desired one. */ else if(!strcmp(thirdCommand,VoiceRecognition.getLastCommand())) { if(analogRead(1)>500) { TextToSpeech.say("yes sir you have left the lights on"); } else if(analogRead(1)<500) { TextToSpeech.say("no sir the lights are turned off"); } } } else if(!strcmp(fourthCommand,VoiceRecognition.getLastCommand())) { digitalWrite(13, HIGH); } else if(!strcmp(fifthCommand,VoiceRecognition.getLastCommand())) { digitalWrite(13, LOW); } } You can download the repo here : https://github.com/GeeveGeorge/AIHomeAutomation/blob/master/ai.ino
