Froggy mundo 5 la pinza café (18 / 21 paso)

Paso 18:

#include < Servo.h >

Elevación del servo;

Servo rotación;

int val = 0;

int Inicio = 10;

int siguiente = 7;

maniquí de int = 0;

const int pwmA = 3;

const int plegadoraUna = 9;

const int dirA = 12;

void setup()

{

Lift.Attach (2); //lift el pin2

Rotate.Attach (5), //rotate en pin 5

pinMode (comienzo, entrada); //pin 10 como entrada

pinMode (a continuación, salida); //pin 7 salida

digitalWrite (next, HIGH);

Lift.Write (80); //upright

Rotate.Write (135), pista de //face

retrasar (2000);

}

void loop()

{

Val=digitalRead(Start);

if(Val==Low)

{dummy = 1;

Lift.Write(85);

Delay(100);

Lift.Write(90);

Delay(100);

Lift.Write(95);

Delay(100);

Lift.Write(100);

Delay(100);

Lift.Write(105);

Delay(100);

Lift.Write(110);

Delay(100);

Lift.Write(115);

Delay(100);

Lift.Write(120);

Delay(100);

Lift.Write(125);

Delay(100);

Lift.Write(130);

Delay(100);

Lift.Write(135);

Delay(100);

Lift.Write(140);

Delay(100);

Lift.Write(145);

Delay(100);

Lift.Write(150);

Delay(100);

Lift.Write(155);

Delay(100);

Lift.Write(160);

Delay(100);

Lift.Write(165);

Delay(100);

Lift.Write(170);

Delay(100);

pinMode(dirA,OUTPUT);

pinMode(brakeA,OUTPUT);

digitalWrite (dirA, LOW); //forward

digitalWrite (plegadoraUna, LOW); //release de freno

analogWrite (pwmA, 255); //motor en max

Delay(20000);

Lift.Write(145);

Delay(100);

Lift.Write(135);

Delay(100);

Lift.Write (125); //lift un poco

Delay(800);

Rotate.Write(130);

Delay(100);

Rotate.Write(125);

Delay(100);

Rotate.Write(120);

Delay(100);

Rotate.Write(115);

Delay(100);

Rotate.Write(110);

Delay(100);

Rotate.Write(105);

Delay(100);

Rotate.Write(100);

Delay(100);

Rotate.Write(95);

Delay(100);

Rotate.Write(90);

Delay(100);

Rotate.Write(85);

Delay(100);

Rotate.Write(80);

Delay(100);

Rotate.Write(75);

Delay(100);

Rotate.Write(70);

Delay(100);

Rotate.Write(65);

Delay(100);

Rotate.Write(60);

Delay(100);

Rotate.Write(55);

Delay(100);

Rotate.Write(50);

Delay(100);

Lift.Write(140);

Delay(100);

Lift.Write(145);

Delay(100);

Lift.Write (150); //at catapulta

Delay(1000);

analogWrite(pwmA,0);

digitalWrite(brakeA,LOW);

Delay(3000);

Lift.Write(80);

Delay (1000); //upright

Rotate.Write(75);

Delay(200);

Rotate.Write(100);

Delay(200);

Rotate.Write(110);

Delay(200);

Rotate.Write(120);

Delay(200);

Rotate.Write(130);

Delay(100);

Rotate.Write(135);

Delay(100);

dummy = 0;

digitalWrite(next,LOW);

Delay(1000);

digitalWrite(next,HIGH);

}}
