Paso 3: código
El código se puede encontrar en los accesorios, asegúrese de que seleccione el puerto adecuado mientras se carga el código y si este tu primer tiempo usando y usted tendrá que descargar el IDE de Arduino e instalar los drivers que vienen junto con el IDE de Arduino Arduino. El puerto serial al cual está conectado el Arduino se puede encontrar en el administrador de dispositivos si está ejecutando windows.
<p>const int buttonPin = 2; // the number of the pushbutton pin<br>const int ledPin = 13; // the number of the LED pin const int led2Pin = 12; const int led3Pin = 11; const int led4Pin = 10; // the number of the LED pin const int led5Pin = 9; const int led6Pin = 7; const int led7Pin = 6; // the number of the LED pin const int led8Pin = 5; const int led9Pin = 4; const int led10Pin = 3; const int speakerOut = 1; // variables will change: int buttonState = 0; // variable for reading the pushbutton status int tastyTimeVariable = 0; // my time variable that has 1 added int i; int n; void setup() { // initialize the LED pin as an output: pinMode(ledPin, OUTPUT); pinMode(led2Pin, OUTPUT); pinMode(led3Pin, OUTPUT); pinMode(led4Pin, OUTPUT); pinMode(led5Pin, OUTPUT); pinMode(led6Pin, OUTPUT); pinMode(led7Pin, OUTPUT); pinMode(led8Pin, OUTPUT); pinMode(led9Pin, OUTPUT); pinMode(led10Pin, OUTPUT); // initialize the pushbutton pin as an input: pinMode(buttonPin, INPUT); pinMode(speakerOut, OUTPUT); delay(3000); } void loop(){ // read the state of the pushbutton value: buttonState = digitalRead(buttonPin); // check if the pushbutton is pressed. // if it is, the buttonState is HIGH: if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(ledPin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led2Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led3Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led4Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led5Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led6Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led7Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led8Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led9Pin, HIGH); } else { } delay(1000); buttonState = digitalRead(buttonPin); if (buttonState == HIGH) { // add to timer tastyTimeVariable = tastyTimeVariable + 1; digitalWrite(led10Pin, HIGH); } else { } delay(1000); digitalWrite(led10Pin, LOW); digitalWrite(led9Pin, LOW); digitalWrite(led8Pin, LOW); digitalWrite(led7Pin, LOW); digitalWrite(led6Pin, LOW); digitalWrite(led5Pin, LOW); digitalWrite(led4Pin, LOW); digitalWrite(led3Pin, LOW); digitalWrite(led2Pin, LOW); digitalWrite(ledPin, LOW); delay(1000); if (tastyTimeVariable == 0) { } else if (tastyTimeVariable == 1) { digitalWrite (ledPin, HIGH); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } } else if (tastyTimeVariable == 2) { digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 3) { digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 4) { digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 5) { digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 6) { digitalWrite (led6Pin, HIGH); digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led6Pin, LOW); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 7) { digitalWrite (led7Pin, HIGH); digitalWrite (led6Pin, HIGH); digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led7Pin, LOW); delay(300L * 1000L); digitalWrite (led6Pin, LOW); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable == 8) { digitalWrite (led8Pin, HIGH); digitalWrite (led7Pin, HIGH); digitalWrite (led6Pin, HIGH); digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led8Pin, LOW); delay(300L * 1000L); digitalWrite (led7Pin, LOW); delay(300L * 1000L); digitalWrite (led6Pin, LOW); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); //sound alarm } else if (tastyTimeVariable == 9) { digitalWrite (led9Pin, HIGH); digitalWrite (led8Pin, HIGH); digitalWrite (led7Pin, HIGH); digitalWrite (led6Pin, HIGH); digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led9Pin, LOW); delay(300L * 1000L); digitalWrite (led8Pin, LOW); delay(300L * 1000L); digitalWrite (led7Pin, LOW); delay(300L * 1000L); digitalWrite (led6Pin, LOW); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); //sound alarm } else if (tastyTimeVariable == 10) { digitalWrite (led10Pin, HIGH); digitalWrite (led9Pin, HIGH); digitalWrite (led8Pin, HIGH); digitalWrite (led7Pin, HIGH); digitalWrite (led6Pin, HIGH); digitalWrite (led5Pin, HIGH); digitalWrite (led4Pin, HIGH); digitalWrite (led3Pin, HIGH); digitalWrite (led2Pin, HIGH); digitalWrite (ledPin, HIGH); delay(300L * 1000L); digitalWrite (led10Pin, LOW); delay(300L * 1000L); digitalWrite (led9Pin, LOW); delay(300L * 1000L); digitalWrite (led8Pin, LOW); delay(300L * 1000L); digitalWrite (led7Pin, LOW); delay(300L * 1000L); digitalWrite (led6Pin, LOW); delay(300L * 1000L); digitalWrite (led5Pin, LOW); delay(300L * 1000L); digitalWrite (led4Pin, LOW); delay(300L * 1000L); digitalWrite (led3Pin, LOW); delay(300L * 1000L); digitalWrite (led2Pin, LOW); delay(300L * 1000L); for (i=0; i < 20; i++) { analogWrite(speakerOut,128); delay(250); digitalWrite(speakerOut, LOW); delay(250); } //sound alarm } else if (tastyTimeVariable > 10) { } }</p>
